ANGLO AMERICA – GROSVENOR COAL MINE
PUMP STATION MCC
Manufactured to AS/NZS 61439 from 316 Stainless Steel
1000A, 50ka/1sec, IP56, Automatic Change Over Switch, with Earth Leakage protected Feeders, Extra Low Voltage PLC Section
DARLINGTON POINT SOLAR FARM
Main Switchboard and Motor Control Centre
Darlington Point Solar Farm is a photovoltaic power station with a capacity of 333 MW DC. HP&CP scope of works involved a partnership with ABB Australia to produce the Low Voltage AC switchboards, namely the Main Switchboard and Motor Control Center.
RARE HARE WINERY & JACKALOPE HOTEL,
MERRICKS NORTH
Site Main Switchboard, Hotel Main Distribution Board, Field Distribution Boards
The Willowcreek Winery site is home to the Rare Hare Food & Wine Store and Jackalope Hotel in Victorias’ Mornington Peninsula.
This project features a Generator back up supply, with an Automatic Transfer Switch in the Main Switchboard. Mains power supply to the site was limited, Zone Selectivity was installed in the Main Switchboard to perform forced coordination between similar sized Circuit Breakers.
EXXON MOBIL – ANGORE CAMP, PAPUA NEW GUINEA
Remote Switchroom with Main Switchboard and,
Field Distribution Boards
A remote camp site for workers of the Angore LNG Pipeline in Papua New Guinea. The project involved a Containerised Switchroom with 3200 amp Site Main Switchboard, powered by several generators, operating with ComAp Generator Synchronisation Panels at the MSB.
Downstream were several heavy duty 316 stainless steel distribution boards to provide power to lighting, power and ancillary services throughout the rest of the facility.
GLENCORE – OAKY CREEK COAL MINE
Pump Station MSB
Manufactured to AS/NZS 61439
3200A, 50ka/1sec, IP56 Main Switchboard, with Earth Leakage protected Feeders, Extra Low Voltage PLC Section.
POINT LEO ESTATE, MERRICKS
Site Main Switchboard and Field Distribution Boards
Located on the iconic Mornington Peninsula, HP&CP designed and manufactured the site switchboards for the Winery, Cellar door and Sculpture Park. Featuring an Automatic Transfer Switch with Generator back up supply, and several lighting pillars scattered throughout the site.
ALBA HOT SPRINGS, FINGAL
Site Main Switchboard, Field Distribution Boards
Manufactured to AS/NZS 61439 from Elsteel Techno Modular System, with 3mm marine grade aluminium outer shell.
Supply Authority Metered Main Switchboard 3200A, 65ka/1sec, Automatic Transfer Switches, several feeders to supply aluminium enclosed distribution boards across the facility.
WOOLWORTHS GROUP
MELBOURNE FRESH DISTRIBUTION CENTRE
PV Solar Grid Protection Switchboard
HP&CP produced two PV Distribution Board’s for the 1.5MW solar array at the Melbourne Fresh Distribution Centre for the Woolworths Group. These Distribution Boards fed 52 Fronius inverters, and featured grid protection and Supply Authority Generation Metering.
